Concert Raya Lift Stage

How to Choose the Right Raya Lifting Stage for Your Concert

Follow the five-step method of "Performance Requirements → Venue Conditions → Drive Method → Safety & Budget → Supplier Capability", and combine typical concert scenarios and drive characteristics to quickly identify the suitable Raya lifting stage.

Five-Step Quick Selection Method

1) Clarify Performance Requirements

Function: Single-point lifting / multi-zone linkage / lifting turntable / track-mounted translation?

Scale classification: Small scale Raya modular stage system/ Medium scale Raya Stage System/ Large scale Raya portable stage.

Elements: Personnel / piano / drum set / LED screen / Truss lighting frame / mechanical props.

Rhythm: Slow lifting/lowering Raya quick-assembly stage / rapid switching Concert Raya Lift Stage / sudden stop/start.

2) Sort Out Venue Conditions

Ground/Underground: Flat ground / lawn / slope; presence of basement / maintenance space.

Floor Height/Clear Space: Lifting stroke + safety clearance + equipment height.

Power Supply/Control Position: Distribution box capacity, grounding, wiring, and console location.

Movement Path: Access for performers/props, assembly/disassembly channels, and time window.

High-Frequency Recommendation for Concerts: Combined configuration of hydraulic direct lift Stage Riser platform + rigid chain Lift Stage for Concerts + screw Lift Stage for Events.

4) Adhere to Safety Standards and Budget

Safety Red Lines: Overload protection, emergency stop, limit/synchronization control, leakage protection, anti-slip platform, anti-pinch design; full machine CE/GB certification; third-party inspection and installation acceptance.

Budget Structure: Equipment cost + transportation & installation + commissioning & programming + maintenance spare parts + insurance; priority to suppliers with local service outlets.

5) Verify Supplier Capabilities

Cases and Qualifications: Concert/theater cases, construction qualifications, safety plans, emergency response plans.

Technical Capabilities: Integrated mechanical/electrical/programming services, on-site troubleshooting, 24-hour response.

Delivery and Spare Parts: Delivery schedule, key spare parts inventory, training, and warranty period.

Typical Scenario Matching

Solo Performer’s Grand Entrance: Screw/scissor lift, 0.1-0.2m/s, ±5mm positioning accuracy, for 1-2 people + lighting equipment.

Precise Positioning for Bands/Pianos: Screw lift, ±3mm positioning accuracy, slow start/stop, 200-300kg per position.

Multi-Zone Rapid Switching: Rigid chain lift, 0.2-0.5m/s, linked synchronization, 3-5 lifting positions.

Heavy Stage Settings/LED Screens on Main Stage: Hydraulic direct lift, long stroke, high load, 0.1-0.3m/s.

Outdoor Lawn/Temporary Venues: Priority to hydraulic direct lift, equipped with adjustable support legs and wind-resistant cables; ground reinforcement pads.
