Custom Shaped Truss Design

Get Latest Price

Contact Now

Description

Product Description

Custom Special-Shaped Trusses

I. Specifications

•Cross-Section Dimensions: Round Tube Truss Options include 200×200 mm, 300×300 mm, 400×400 mm, 520×760 mm, and other standard frames. Custom circular, arc, diamond, star, or parametrically designed free-form shapes are also available.

•Single-Segment Lengths: Standard stock lengths of 1 m, 2 m, 3 m, and 4 m. Round Tube Truss System Custom longer or shorter segments can be cut to order.

•Main Tube Specifications: Sizes range from φ50×2–5 mm, φ30×2 mm, to φ25×2 mm, Steel Round Tube Truss with varying wall thicknesses to accommodate different spans and load capacities (single-point support from 200 kg to 2 tons).

•Connection Methods: Lightweight Round Tube Truss Pin-type, bolted, or hybrid connections. On-site welding is unnecessary, and assembly/disassembly can be completed in as little as 10 minutes per segment.

II. Advantages

•Design Flexibility: Modular Round Tube Truss Capable of forming any spatial curve in a single process, with node alignment errors under 1 mm.

•Lightweight Construction: Aluminum trusses reduce self-weight by 60% compared to conventional materials for the same span, cutting transport and hoisting costs by half.

•Rapid Setup & Dismantling: Modular connections enable installation by just 2–4 people without welding or heavy machinery.

•Reusability: Structural Round Tube Truss Anodized and powder-coated finishes allow 5–8 years of maintenance-free use and over 100 reuse cycles.

•Structure as Decoration: The exposed Truss itself serves as spatial art, eliminating the need for additional decorative costs.

III. Materials: Balancing Lightweight and Strength

•Aluminum Alloy (Commonly Used)

– Grades: 6061-T6 / 6082-T6

– Density: 2.7 g/cm³ (only 1/3 that of steel), Custom Truss Structure Solution reducing handling effort

– Anodized layer ≥10 μm, providing 5–8 years of rust-free outdoor use

•Steel (Optional for High Loads)

– High-strength grades including Q235B, Q355B, Q420GJC

– Custom Geometry Truss Hot-dip galvanized or fluorocarbon spray coatings, with anti-corrosion levels up to C5-M

•Connectors

– Pins: Made from 45# zinc-plated steel, Special Shape Truss System with 600 MPa tensile strength

– Bolts: Grade 8.8 high-strength carbon steel, hot-dip galvanized for rust prevention
